ZTW UBEC 12A

FEATURES

• Switch mode
• Easy to set up and install.
• Battery polarity reversal protection.
• Electromagnetic interference reduction ensures optimum receiver performance.
• LED status indicator.
• Output voltage - 5.0V, 5.5V, 6.0V, 6.5V, 7.0V, 8.0V
• Input voltage - 7V - 60V (2-14S Lipo, 6-50 cell NiMH)
• Continues current output - 12A
• Peak current output - 18A

DETAILS

A UBEC is needed if your Electronic Speed Controller (ESC) does not have a built in Battery Elimination Circuit (BEC). There's also a requirement to fit a UBEC where the ESC's BEC is inadequate to power the number and / or size of servos being used. The ZTW UBEC range satisfies this requirement by supporting continuous simultaneous servo operations, thus eliminating the possibility of overloading your speed controller's BEC during periods of high peak demand (as might be experienced during extreme aerobatics).

Specification:

Output:	Adjustable 5V / 5.5V / 6V / 6.5V / 7V / 8V at 12A
Input voltage:	7 - 60V
Output current:	12A continuous / 18A burst
Size (mm):	60 x 34 x 15
Weight (g):	51
